GEP-9999: DUMONT

  • Issue: #9999
  • Status: Memorandum

(See status definitions.)

Introduction

Authentication and authorization are necessary tasks for a great many applications: it can obviously be critical to ensure that only authorized users can access specific resources and perform certain actions. In a distributed architecture, it is often very useful to centralize these tasks in a single service, which can then be used by all components of the system. This approach allows for consistent policy enforcement, easier management of access control rules, and the ability to update policies dynamically without requiring changes to individual services.

A common implementation pattern for centralized authentication and authorization is to give a centralized API gateway or proxy the ability to offload authorization decisions to an external service: when a request arrives at the proxy, the proxy sends a request to this external service, and the service responds with the authorization decision. This pattern is simple to implement and to reason about, while still allowing a great amount of flexibility in how authorization decisions are made.

The Envoy Proxy has had this ability since its 1.7.0 release in June 2018, via its external authorization (ext-authz) filter. The ext-authz filter can speak to an external authorization service using either HTTP or gRPC, but the protocol used for communication was never been formally specified nor even named. This document aims to fill that gap by providing the protocol with a formal specification, as well as a name. Since the name is not yet finalized, we will refer to the system as "DUMONT" for now.

Although DUMONT was first implemented in the Envoy Proxy, its design is not specific to Envoy, and is suitable for use with any other proxy or API gateway. However, one challenge with standardizing DUMONT is that its gRPC variant currently uses message types that contain elements that are specific to Envoy, and in fact the messages are currently defined in the Envoy repository. DUMONT MUST NOT be considered fully standardized until these message types have found a home outside the Envoy repository, and the Envoy-specific elements have been refactored out of the messages.

Terminology

The key words "MUST", "MUST NOT", "REQUIRED", "SHALL", "SHALL NOT", "SHOULD", "SHOULD NOT", "RECOMMENDED", "MAY", and "OPTIONAL" in this document are to be interpreted as described in BCP 14 (RFC2119 and RFC8174) when they appear in all capitals, as shown here.

In this document, we will refer to the following request flow, showing a basic request from a client to a workload via a gateway:

sequenceDiagram
  participant Client
  participant Gateway
  %% participant DUMONT Server
  participant Workload

  autonumber
  Client ->>+ Gateway: Request
  Gateway ->>+ Workload: Request
  Workload ->>- Gateway: Response
  Gateway ->>- Client: Response

When DUMONT is involved, the flow also includes a DUMONT server:

sequenceDiagram
  participant Client
  participant Gateway
  participant DUMONT Server
  participant Workload

  autonumber
  Client ->>+ Gateway: Request
  Gateway ->>+ DUMONT Server: DUMONT Request
  DUMONT Server ->>- Gateway: DUMONT Response
  alt if ALLOW
    Gateway ->>+ Workload: Request
    Workload ->>- Gateway: Response
  end
  Gateway ->>- Client: Workload or<br/>DUMONT Response

  • Client always refers to the entity that first initiates a request. In most cases where DUMONT is used, the client will be taking action on behalf of a human user, though this is not a requirement of DUMONT.

  • Gateway always refers to the entity responsible for implementing authorization, routing, etc. In the context of DUMONT, the gateway acts as a DUMONT client, sending requests to the DUMONT server for authorization decisions.

  • Workload always refers to the entity that is the final destination of the request, which is typically a service or application that processes the request and returns a response. The workload is not directly involved in the DUMONT protocol but is the target of the request after authorization is granted by the DUMONT server.

  • DUMONT Server always refers to the entity that implements the DUMONT protocol to receive authorization requests from gateways, evaluate them, and return authorization decisions. A single DUMONT server can typically be used by multiple gateways simultaneously.

DUMONT Protocol Overview

When the gateway receives a request that needs to be authorized, it sends a DUMONT Request to the DUMONT server with the details of the request. The DUMONT server MUST respond with either a DUMONT ALLOW response, indicating that the request is authorized to proceed, or a DUMONT DENY response, indicating that the request is not authorized to proceed and providing a response which the gateway MUST forward to the client.

If the DUMONT server responds with a DUMONT ALLOW response, the gateway forwards the request to the workload. The gateway MUST NOT forward the DUMONT ALLOW response to the client, but the DUMONT ALLOW response MAY include HTTP headers which the gateway MUST include in the forwarded request to the workload.

If the DUMONT server responds with a DUMONT DENY response, the gateway MUST forward the DUMONT DENY response to the client. The DUMONT DENY response includes an HTTP status code, headers, and body, allowing the DUMONT server to control the client's experience when a request is denied. The gateway MUST NOT forward the original request to the workload in this case.

Forwarding the DUMONT DENY response to the client is critical. DUMONT is intended to be applicable to a wide variety of authentication flows ranging from (for example) HTTP Basic Auth to (for example) OAuth2. As such, the DUMONT protocol deliberately gives the DUMONT server authority over what exactly must be sent to the client in the case of a DUMONT DENY response, so that the system can meaningfully participate in the widest possible set of authentication flows.

DUMONT Protocol Variants

DUMONT is defined with both HTTP and gRPC variants. Where possible, implementations of DUMONT SHOULD support both variants, but they MAY support only one.

The two variants serve the same function and are largely equivalent, with the critical difference that the gRPC variant supports more features because it encapsulates the client request in a gRPC message, where the HTTP variant simply uses a standard HTTP request that mimics the client request. This difference has important implications, which allow the DUMONT gRPC variant to support more features than the HTTP variant.

As an illustration, consider the following example of a request from the client:

POST /api/v1/resource HTTP/1.1
Host: example.com
Authorization: Bearer <token>
Content-Type: application/json
Content-Length: 27
X-Custom-Header: custom-value

{
  "key": "value"
}

In the gRPC variant, this request would be encapsulated in a CheckRequest gRPC message. Assuming that DUMONT client is not configured to forward the body, the CheckRequest might look like this:

CheckRequest:
  attributes:
    source: ...
    ...
    request:
      time: ...
      http:
        method: "POST"
        path: "/api/v1/resource"
        headers:
          Host: "example.com"
          Authorization: "Bearer <token>"
          Content-Type: "application/json"
          Content-Length: "27"
          X-Custom-Header: "custom-value"

However, in the HTTP variant, the request would be sent as a standard HTTP request to the DUMONT server, and in that case, the headers MUST NOT all be copied unmodified to the DUMONT request. Instead, the HTTP variant defines the concept of allowed request headers, which is the subset of HTTP headers that are explicitly configured to be forwarded. The DUMONT HTTP request might therefore look like this:

POST /api/v1/resource HTTP/1.1
Host: example.com
Authorization: Bearer <token>
Content-Length: 0

Since it has no body, the Content-Length header is set to 0, and the Content-Type header is omitted entirely. Likewise, X-Custom-Header would typically not be configured as an allowed request header, so it would be stripped from the request before forwarding it to the DUMONT server.

Suppose that in our example, the DUMONT server decides to allow the request. In both variants, the DUMONT server responds with a DUMONT ALLOW response, which MAY include a set of headers to be copied into the forwarded request to the workload. For example, suppose that our DUMONT server wants to add a Set-Cookie header and a custom X-DUMONT-Magic header:

Set-Cookie: sessionId=abc123; Path=/; HttpOnly
X-DUMONT-Magic: 42

In the DUMONT gRPC variant, an OK status and the new headers are included in the CheckResponse message:

CheckResponse:
  status: OK
  http_response:
    ok_response:
      headers:
        - key: "Set-Cookie"
          value: "sessionId=abc123; Path=/; HttpOnly"
        - key: "X-DUMONT-Magic"
          value: "42"

However, in the DUMONT HTTP variant, the DUMONT ALLOW response is a standard HTTP response, which MUST use an HTTP 200 status to indicate the DUMONT ALLOW response, and which MUST include the headers to be copied into the request inline as normal HTTP headers (because that's the only real way to use HTTP for this). In turn, this requires the DUMONT HTTP variant to define a set of allowed authorization headers, since it is not appropriate to copy all the HTTP headers from the DUMONT server response to the forwarded request:

HTTP/1.1 200 OK
Set-Cookie: sessionId=abc123; Path=/; HttpOnly
X-DUMONT-Magic: 42
Content-Length: 0

The DUMONT HTTP variant exists because it often provides a simpler path to adoption: gateways generally already include everything needed to make DUMONT HTTP requests, and in many cases, existing HTTP-based authorization services can be used as DUMONT servers with minimal changes. The tradeoff is that the DUMONT HTTP variant MUST be very careful indeed with handling HTTP headers -- in particular, the DUMONT HTTP variant is not appropriate for use in cases where it is not possible to define the allowed request headers ahead of time.

The DUMONT gRPC variant, by contrast, does not need to rely on the limited capabilities of HTTP, and as such can be used in wider range of use cases. The tradeoff is that the additional features come with additional complexity: since the gRPC messages involved took considerable advantage of types that were already available within the Envoy proxy, adopting the DUMONT gRPC variant outside of Envoy involves a certain amount of work to set up data structures in exactly the same way that Envoy does.

Given all of the above, the DUMONT gRPC variant is recommended for new implementations, but the DUMONT HTTP variant MUST be used as the reference variant wherever this document leaves questions about the semantics of DUMONT. This is because the HTTP variant is more constrained by the transport protocol: the gRPC variant should be able to support anything supported by the HTTP variant, but the converse is not true.

DUMONT Request Overview

The DUMONT request provides the DUMONT server with all the information it needs to make an authorization decision, and includes:

  • The HTTP verb (e.g., GET, POST, PUT, DELETE) of the request

  • The HTTP path of the request (including any query parameters)

  • The request headers (or, in DUMONT HTTP, the allowed request headers)

  • A (usually configurable) section of the beginning of the request body, not to exceed the maximum forwarded body size

DUMONT HTTP Mandatory Request Headers

In DUMONT HTTP implementations, the following headers MUST always be included in the allowed request headers, and as such MUST always be included in a DUMONT HTTP request:

  • Authorization
  • Cookie
  • From
  • Forwarded
  • Proxy-Authorization
  • User-Agent
  • X-Forwarded-For
  • X-Forwarded-Host
  • X-Forwarded-Proto

DUMONT Response Overview

The DUMONT response is the response sent by the DUMONT server to the gateway in response to a DUMONT request. It can be either a DUMONT ALLOW response or a DUMONT DENY response.

DUMONT ALLOW Response

The DUMONT ALLOW response indicates that the request is authorized to proceed.

sequenceDiagram
participant Client
participant Gateway
participant DUMONT Server
participant Workload

autonumber
Client ->>+ Gateway: Request
Gateway ->>+ DUMONT Server: DUMONT Request
DUMONT Server ->>- Gateway: DUMONT ALLOW Response
Gateway ->>+ Workload: Request
Workload ->>- Gateway: Response
Gateway ->>- Client: Response

In addition to the ALLOW decision, a DUMONT ALLOW response includes a set of headers that are to be copied from the DUMONT ALLOW response into the client request before it is forwarded to the workload. In DUMONT HTTP, only headers from the allowed authorization headers are copied, while in DUMONT gRPC, all the headers supplied are copied.

If a header to be copied is already present in the original request, the value from the DUMONT ALLOW response MUST replace the value from the original request.

DUMONT HTTP Mandatory Allowed Authorization Headers

In DUMONT HTTP implementations, the following headers MUST always be included in the allowed authorization headers, and as such MUST always be copied from a DUMONT HTTP ALLOW response to the client request before forwarding the request to the workload:

  • Authorization
  • Location
  • Proxy-Authenticate
  • Set-Cookie
  • WWW-Authenticate

DUMONT DENY

The DUMONT DENY response indicates that the request is not authorized to proceed. In this case, the DUMONT server MUST provide a response that the gateway MUST forward to the client: in DUMONT gRPC, the HTTP status code, headers, and body are explicitly defined in the message, while in DUMONT HTTP, the DUMONT DENY response is itself the custom response that MUST be forwarded to the client.

sequenceDiagram
  participant Client
  participant Gateway
  participant DUMONT Server
  participant Workload

  autonumber
  Client ->>+ Gateway: Request
  Gateway ->>+ DUMONT Server: DUMONT Request
  DUMONT Server ->>- Gateway: DUMONT DENY Response
  Gateway ->>- Client: DUMONT DENY Response

The gateway MAY do further gateway-dependent processing of the DUMONT DENY response before forwarding it to the client, but it MUST NOT alter the HTTP status code defined by the DUMONT DENY response, and it SHOULD NOT alter the headers from the DUMONT DENY response. Additionally, the gateway MUST NOT forward the original request to the workload in any case where a DUMONT DENY response is received from the DUMONT server.

As noted earlier, forwarding the DUMONT DENY response to the client is critical. DUMONT is intended to be applicable to a wide variety of authentication flows ranging from (for example) HTTP Basic Auth to (for example) OAuth2. As such, the DUMONT protocol deliberately gives the DUMONT server authority over what exactly must be sent to the client in the case of a DUMONT DENY response, so that the system can meaningfully participate in the widest possible set of authentication flows.

DUMONT Error Responses

Any response other than a DUMONT ALLOW or DUMONT DENY response (for example, a connection reset, or a response that does not conform to the DUMONT protocol) MUST be treated as an error. In this case, the gateway MUST return an HTTP error response to the client, and MAY include additional information about the error in the response body.

The gateway MAY permit configuring the HTTP status code to be returned in the event of a DUMONT error response. If not explicitly configured otherwise, the gateway MUST return a 403 Forbidden status code for a DUMONT error response.

DUMONT HTTP Specifics

DUMONT HTTP ALLOW Response

The DUMONT HTTP ALLOW response is defined as a DUMONT response with an HTTP status of 200 OK. A DUMONT response with an HTTP status code other than 200 MUST NOT be interpreted as a DUMONT ALLOW response. This includes other 2yz status codes, such as 201 Created or 202 Accepted, which MUST NOT be interpreted as DUMONT ALLOW responses.

DUMONT HTTP DENY Response

DUMONT HTTP DENY responses are defined as DUMONT responses with an HTTP status code other than 200 OK or 5yz server errors. Any such response MUST be forwarded to the client as described above.

DUMONT HTTP Error Responses

Any other response to a DUMONT HTTP request (for example, a timeout, or a 503 Service Unavailable response) MUST be treated as an DUMONT error response. In this case, the gateway MUST return an HTTP error response to the client, and MAY include additional information about the error in the response body.

DUMONT HTTP Examples

DUMONT HTTP ALLOW Response Example

TBA

DUMONT HTTP DENY Response Example

TBA

DUMONT gRPC Specifics

Although DUMONT as a protocol is applicable beyond Envoy, the DUMONT gRPC message types are currently, and unfortunately, more tied to Envoy than the rest of the protocol. In particular, the most authoritative protobuf definitions for the DUMONT gRPC messages currently reside in the Envoy repo, and some elements of the current protobuf definitions are more Envoy-specific than is appropriate for an open standard.

In order for the DUMONT protocol to be considered standardized, the DUMONT gRPC message definition MUST be moved out of the Envoy repository into a more neutral location, and the Envoy-specific metadata MUST be refactored. For the moment, though, rather than reproducing the message definitions in this document, we will instead present high-level descriptions of the messages, and give links to the Envoy repo for the full current protobuf definitions.

The DUMONT Authorization Service

At the highest level of the DUMONT gRPC variant is the Authorization service defined in api/envoy/service/auth/v3/external_auth.proto in the Envoy repository. This service defines a single Check RPC method, which takes a CheckRequest message as an argument and returns a CheckResponse message. Both of these messages are also defined in api/envoy/service/auth/v3/external_auth.proto.

DUMONT gRPC CheckReqest

CheckRequest is a wrapper around the Envoy AttributeContext message, defined in api/envoy/service/auth/v3/attribute_context.proto. This message contains a wide variety of information about the request:

  • source: information about the original client of the request
  • destination: information about where the gateway accepted the request (this is not the destination workload; that won't be known yet)
  • request: information about the request itself, including the HTTP verb, path, headers, and body
  • tls_session: information about the TLS session, if any, that was used to establish the connection between the client and the gateway

There are also three elements that are very Envoy-specific, representing metadata associated with the Envoy configuration at multiple levels. These elements MUST be refactored before the DUMONT gRPC variant can be considered standardized:

  • context_extensions, metadata_context, and route_metadata_context: Envoy-specific metadata at several different levels

DUMONT gRPC CheckResponse

CheckResponse contains four elements:

  • status: a google.rpc.Status message indicating the result of the authorization check.

  • ok_response: an OkHTTPResponse message that MUST be provided if status is OK. This is the DUMONT gRPC ALLOW response.

  • denied_response: a DeniedHTTPResponse message that MUST be provided if status is anything other than OK. This is the DUMONT gRPC DENY response.

  • dynamic_metadata: gateway-dependent metadata that can be consumed by the gateway in its next routing step

Note that dynamic_metadata is not particularly specific to Envoy; the DUMONT protocol can be standardized without needing to refactor this element.

Exactly one of ok_response or denied_response MUST be provided in a CheckResponse. The status field MUST be set to OK if ok_response is present and MUST NOT be set to OK if denied_response is present.

CheckResponse, OkHTTPResponse, and DeniedHTTPResponse are all currently defined in api/envoy/service/auth/v3/external_auth.proto in the Envoy repository.

DUMONT gRPC ALLOW Response

The DUMONT gRPC ALLOW response is defined as a DUMONT response with status set to OK and the ok_response field set to a valid OkHTTPResponse message.

The OkHTTPResponse message contains:

  • headers: a list of HeaderValueOptions defining headers to added to the forwarded request to the workload

  • headers_to_remove: a list of strings naming headers to be removed from the forwarded request to the workload

  • query_parameters_to_set: a list of QueryParameters defining query parameters to be added to the forwarded request to the workload

  • query_parameters_to_remove: a list of strings naming query parameters to be removed from the forwarded request to the workload

  • response_headers_to_add: a list of HeaderOptionValues defining headers to be added to the response going back to the client

The HeaderValueOption and QueryParameter messages are defined in api/envoy/type/v3/base.proto in the Envoy repository. Both contain a name and a value, but the HeaderValueOption message also contains an append_action element to indicate the action to take when the header to be added is already present in the request.

The OkHTTPResponse message also contains some deprecated elements which MUST be removed as part of the DUMONT standardization process:

  • dynamic_metadata: superseded by the dynamic_metadata field in CheckResponse
Headers that Cannot be Removed

A gateway MUST NOT remove HTTP/2 pseudo-headers (such as :method, :authority, :scheme, and :path) or the Host header from the forwarded request to the workload. If headers_to_remove mentions any of these headers, the gateway MUST ignore the request to remove them.

Open Questions
  • Should response_headers_to_add be part of the DUMONT standard? What are the use cases here?

DUMONT gRPC DENY Response

The DUMONT gRPC DENY response is defined as a DUMONT response with status set to DENIED and the denied_response field set to a valid DeniedHTTPResponse message.

The DeniedHTTPResponse message contains:

  • status: the HTTP status to return to the client

  • headers: a list of HeaderValueOptions providing the complete set of headers to be included in the response to the client

  • body: a string containing the body to be included in the response to the client

As with the DUMONT HTTP DENY, the DUMONT gRPC DENY response is intended to give the DUMONT server full authority over the response sent to the client in the case of a denied request. The gateway MUST forward the DUMONT DENY response to the client; it MUST NOT alter the HTTP status provided by the DUMONT server, and it SHOULD NOT alter the headers or body provided by the DUMONT server.

DUMONT gRPC Error Responses

Any other response to a DUMONT gRPC request (for example, a timeout) MUST be treated as an DUMONT error response. In this case, the gateway MUST return an HTTP error response to the client, and MAY include additional information about the error in the response body.

DUMONT gRPC Examples

DUMONT gRPC ALLOW Response Example

TBA

DUMONT gRPC DENY Response Example

TBA

DUMONT Gateway Configuration

The gateway SHOULD allow its operator to configure the following characteristics of the DUMONT client, at minimum:

  • The DUMONT server to which the gateway should send requests

  • The set of allowed request headers

  • The set of allowed authorization headers

  • The maximum forwarded body size

The gateway MAY allow configuring additional functionality (for example, Envoy allows the operator to configure whether the gateway should truncate message bodies longer than the maximum forwarded body size, or whether the gateway should instead return a 413 Request Entity Too Large response in such cases).

The gateway MUST allow its operator to configure the DUMONT client at a global level, and SHOULD allow configuring with finer granularities (for example, per route).
